pyMarkdown 速记¶

约 776 个字 • 142 行代码预计阅读时间 6 分钟

这是一个pyMarkdown速查表

markdown基本语法¶

下面是一些常用的markdown操作记录。详细内容请点击 Markdown 基本语法

标题强调引用列表代码链接图片表格脚注

# 这是一级标题
## 这是二级标题
### 这是三级标题

*斜体*
**粗体**
***斜体加粗***
--- 分隔符
~~删除线~~
^^下划线^^
==高亮==
++shift+alt++ +`A`

效果

Text can be deleted and replacement text added.
This can also becombined into onea single operation.
Highlighting is also possible and comments can be added inline.

Shift+Alt +A

引用内容

1. 有序列表
     - [x] 无序列表
         - [ ] 缩进
2. 有序列表

有序列表
- 无序列表
  - 缩进
有序列表

单行代码

代码块标题

    ```text title="代码块标题"
    多行代码块
    ```

print("hello world")

Advanced code block

    ``` py hl_lines="3-5" title="代码块标题"
    def bubble_sort(items):
        for i in range(len(items)):
            for j in range(len(items) - 1 - i):
                if items[j] > items[j + 1]:
                    items[j], items[j + 1] = items[j + 1], items[j]
    ```

代码块标题

def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]

***[链接名称](链接地址 "悬停label")***
<直链>

博客地址

https://dixilog.github.io

[![图片名称](图片地址 "悬停label")](超链接地址)
![封面](https://i.ibb.co/ZfyqjB0/image.webp "封面"){style="zoom: 75%;"}

| 表头1 | 表头2 | 表头3 |
| :--- | :---: | -----:|
| 单元格 <br>  换行 | 单元格2222222 | 单元格333333 |
| `左对齐` | **居中** | 右对齐 |

表头1	表头2	表头3
单元格换行	单元格2222222	单元格333333
`左对齐`	居中	右对齐

Here's a simple footnote.[^1]

[^1]: 这是你的脚注。

Here's a simple footnote.¹

markdown-extensions¶

display basic usage of markdown in python
details click here
关于 Reference，demo 取自官方文档

缩写¶

缩写格式,也可作注释(中文则需要空格分隔)

The HTML specification is maintained by the W3C.

*[HTML]: Hyper Text Markup Language
*[W3C]:  World Wide Web Consortium

Example：The HTML specification is maintained by the W3C.

标题tag¶

标题tag，用于文档内跳转

# 标题1{: #title1 }

[name_yourself](#title1)

Example:跳转到基本语法部分

可能出现单点无效的情况，需要再次单击

段落缩进¶

冒号 + tab

dixi
:   dixiLOG
    a magic bolg
    :   what c i say?
        amazing!

dixi

dixiLOG
a magic bolg: what c i say?
amazing!

高亮块¶

可能是使用最多的部分

格式

标准高亮块
!!! type "name"
    content

高亮框
!!! type ""
    content

高亮分割线
!!! type ""

info

这里是info块

success

这里是success块

tip

这里是tip块

quote

这里是quote块

note

这里是note块

abstract

这里是abstract块

question

这里是question块

example

这里是example块

warning

这里是warning块

failure

这里是failure块

bug

这里是bug块

danger

这里是danger块

折叠与分栏¶

折叠格式

??? type "name"
    content

分栏格式

=== "name1"
    content

=== "name2"
    content

分栏1分栏2

danger

这里是danger块

danger

这里是danger块

目录生成¶

```text title="就一行"
[TOC]
```

渲染结果

Contents

pyMarkdown 速记
- markdown基本语法
- markdown-extensions
  - 缩写
  - 标题tag
  - 段落缩进
  - 高亮块
  - 折叠与分栏
  - 目录生成
  - 注释
  - 按钮
  - 图 diagrams
  - Grid
  - 公式

注释¶

```text title="一般注释"
Lorem ipsum dolor sit amet, 是时(1) consectetur adipiscing elit.
{ .annotate }

1.  :man_raising_hand: 我`是`**注**^^释^^
```

Lorem ipsum dolor sit amet, (1) consectetur adipiscing elit.

我是注释

```text title="套娃注释"
Lorem ipsum dolor sit amet, (1) consectetur adipiscing elit.
{ .annotate }

1.  :man_raising_hand: I'm an annotation! (1)
    { .annotate }

    1.  :woman_raising_hand: I'm an annotation as well!
```

Lorem ipsum dolor sit amet, (1) consectetur adipiscing elit.

I'm an annotation! (1)
1. I'm an annotation as well!

按钮¶

格式

[icon search :material-file-find:](https://squidfunk.github.io/mkdocs-material/reference/icons-emojis/#search){ .md-button }

icon search

Icon 和 Emojis

图 diagrams¶

基于 mermaid 库，支持流程图、时序图、状态机、类图等

详细语法参见开发文档

流程图 Flow chart

    ``` mermaid
    graph LR
    A[Start] --> B{Error?};
    B -->|Yes| C[Hmm...];
    C --> D[Debug];
    D --> B;
    B ---->|No| E[Yay!];
    ```

graph LR
A[Start] --> B{Error?};
B -->|Yes| C[Hmm...];
C --> D[Debug];
D --> B;
B ---->|No| E[Yay!];

时序图 Sequence diagram

    ``` mermaid
    sequenceDiagram
    autonumber
    Alice->>John: Hello John, how are you?
    loop Healthcheck
        John->>John: Fight against hypochondria
    end
    Note right of John: Rational thoughts!
    John-->>Alice: Great!
    John->>Bob: How about you?
    Bob-->>John: Jolly good!
    ```

sequenceDiagram
  autonumber
  Alice->>John: Hello John, how are you?
  loop Healthcheck
      John->>John: Fight against hypochondria
  end
  Note right of John: Rational thoughts!
  John-->>Alice: Great!
  John->>Bob: How about you?
  Bob-->>John: Jolly good!

状态机 State diagram

    ``` mermaid
    stateDiagram-v2
    state fork_state <<fork>>
        [*] --> fork_state
        fork_state --> State2
        fork_state --> State3

        state join_state <<join>>
        State2 --> join_state
        State3 --> join_state
        join_state --> State4
        State4 --> [*]
    ```

stateDiagram-v2
  state fork_state <<fork>>
    [*] --> fork_state
    fork_state --> State2
    fork_state --> State3

    state join_state <<join>>
    State2 --> join_state
    State3 --> join_state
    join_state --> State4
    State4 --> [*]

类图 Class diagram

    ``` mermaid
    classDiagram
    Person <|-- Student
    Person <|-- Professor
    Person : +String name
    Person : +String phoneNumber
    Person : +String emailAddress
    Person: +purchaseParkingPass()
    Address "1" <-- "0..1" Person:lives at
    class Student{
        +int studentNumber
        +int averageMark
        +isEligibleToEnrol()
        +getSeminarsTaken()
    }
    class Professor{
        +int salary
    }
    class Address{
        +String street
        +String city
        +String state
        +int postalCode
        +String country
        -validate()
        +outputAsLabel()
    }
    ```

classDiagram
  Person <|-- Student
  Person <|-- Professor
  Person : +String name
  Person : +String phoneNumber
  Person : +String emailAddress
  Person: +purchaseParkingPass()
  Address "1" <-- "0..1" Person:lives at
  class Student{
    +int studentNumber
    +int averageMark
    +isEligibleToEnrol()
    +getSeminarsTaken()
  }
  class Professor{
    +int salary
  }
  class Address{
    +String street
    +String city
    +String state
    +int postalCode
    +String country
    -validate()
    +outputAsLabel()
  }

Grid¶

格式

<div class="grid cards" markdown>

-   :material-clock-fast:{ .lg .middle } **Set up in 5 minutes**

    ---

    Install [`mkdocs-material`](#) with [`pip`](#) and get up
    and running in minutes

    [:octicons-arrow-right-24: Getting started](#)

-   :fontawesome-brands-markdown:{ .lg .middle } **It's just Markdown**

    ---

    Focus on your content and generate a responsive and searchable static site

    [:octicons-arrow-right-24: Reference](#)

-   :material-format-font:{ .lg .middle } **Made to measure**

    ---

    Change the colors, fonts, language, icons, logo and more with a few lines

    [:octicons-arrow-right-24: Customization](#)

-   :material-scale-balance:{ .lg .middle } **Open Source, MIT**

    ---

    Material for MkDocs is licensed under MIT and available on [GitHub]

    [:octicons-arrow-right-24: License](#)

</div>

Set up in 5 minutes

Install mkdocs-material with pip and get up and running in minutes

Getting started
It's just Markdown

Focus on your content and generate a responsive and searchable static site

Reference
Made to measure

Change the colors, fonts, language, icons, logo and more with a few lines

Customization
Open Source, MIT

Material for MkDocs is licensed under MIT and available on [GitHub]

License

公式¶

simpleTex 扫描复制粘贴即可

这是你的脚注🤣 ↩
